Merida e-One Forty 4000 2020 Electric Full Suspension Mountain Bike

Season:2020

Brand:Merida

Code:K84

2020 Merida eOne-Forty 4000 electric mountain bike Key Features:



THERMO GATE

Forged aluminium part integrated into the headtube.  Works like a chimney so hot air can rise up and escape. When riding, heat build up from the battery is not usually an issue, but if the bike was laid in the sun for a long time heat could build up.

WHEEL SIZE

Mixed wheel sizes to get the best of both worlds. 29" front wheel for better ‘roll over
performance’ with a 2.5" wide tyre for precise steering. 27.5" rear wheel with 2.6" tyres give
maximum traction and comfort. The smaller rear wheel size allows shorter chainstays for a more agile and playful character.

INTERNAL BLOCK

To prevent the fork crown hitting the down tube we use an ‘Internal Block’ integrated into the frame. A clamp is installed on the fork steerer. If the steering angle is too extreme the clamp hits the rubber protection block inside the frame. Just in case the clamp does rotate on the steere, there's additional rubber protection under the head tube.

EASY CHARGING

The internal battery can be accessed easily, pulling a rubber strap, sliding forward the panel and opening, the battery can then be removed by a small turn of an Allen Key (provided).  But the battery doesn't need to be removed as a satellite charging port can be used.

RATTLE FREE

Two part battery cover, the outer layer reduces noise through its soft material and tight fit, while the hard plastic inner layer gives it the structural shape.  Key components i.e. the rubber strap and o-rings, can be replaced.  Almost all connection points between battery and frame have a rubber layer between them too.

BOTTLE BOSSES AND CABLE ROUTING

 A new clamp system makes it easy to organise and route cables inside the downtube whilst also providing bottle bosses on the outside. Bottle cages can be put in two positions. The upper one must be used when a piggyback shock is mounted. For Gen II a bottle can be mounted to all frame sizes.

BATTERY WAKE UP

If the bike has not been used for more than 6 months, or when the battery of the on/off switch is empty (this battery is normally charged by the main battery) it's necessary to wake the battery up again, simply push a 4mm Allen key (on the Merida Expert TR axle) through the hole on the downtube and press the hidden button underneath

Bike Despatch
Technical Information



Frame Carbon front triangle with easily removable integrated battery, satellite on/off switch, on-bike charging port and “thermo gate”Carbon
Fork Suntour Raidon 34 LOR; Air; 140 mm travel; Tapered steerer; 51mm fork offset
Shock RS-EDGE-TR-LO-R8-M6; lockout
Rims Merida Comp TR; 29 mm inner width; 29" front and 27.5" rear
Hubs Shimano MT400-B; 110 x 15mm axle; 32 spoke; Centerlock front and Shimano MT400-B; 148 x 12mm axle; 36 spoke; Centerlock rear with Merida Comp TR rear axle including removeable lever,
Tyres Maxxis DHF; 29" x 2.5 "; Kevlar bead - folding; EXO TR Dual Compound front and Maxxis DHR II; 27.5" x 2.6 "; Kevlar bead - folding; EXO TR Dual Compound rear
Mechs Shimano Deore Shadow+
Cassette Shimano HG500; 11-42 teeth, 10 speed
Chain KMC e10S
Shifters Shimano Deore
Chainset Shimano CRE70-B; 34 teeth with Shimano E8000 crank
Brakes Shimano MT-420; 4 piston front and MT-400; 2 piston rear hydraulic disc brakes with Shimano RT30; 203 mm front and Shimano RTEM300; 180 mm rear rotors
Handlebar Merida Expert eTR; 780 mm wide; 20 mm rise
Wheel Size 29" / 27.5"
Speed 10
Bottom Bracket Shimano E7000; 60NmShimano Steps E7000; 60Nm motor
Pedals VP; VPE-537
Stem Merida Expert eTR; 35 mm diameter; 0 degree rise
Saddle Merida Comp CC
Seatpost Merida Comp TR; 30.9 mm diameter; 0mm layback S: 100 mm travel - M/L/XL/XXL: 125 mm travel
Drive Unit Shimano Steps E7000
Battery Shimano E8035 - 504Wh



Sizing Information
FRAME SIZE BODY HEIGHT
XS < 163 cm
S 157 - 173 cm
M 167 - 183 cm
L 177 - 190 cm
XL > 187 cm
